Low Pressure Vapor Hose And Water Hose Are Oil And Heat Resistant
FOR ALL YOUR COOLANT, VAPOR LPG, VACUUM, AND AIR CLEANER HOSE REQUIREMENTS
All styles of hose may be supplied in bulk, or cut to custom lengths, with or without hose ends installed. When ordering custom length hoses, order by PART NUMBER-LENGTH IN INCHES. Example: The part number for an 18" length of 5/8" Vapor hose is H715-18.
| Part Number |
Type |
I.D |
O.D |
Clamp Size |
Material |
Reinforcement |
| H715 |
Vapor |
5/8" |
|
8H |
Neoprene |
Phosphorus Bronze Steel Wire |
| H736 |
Vapor |
3/4" |
|
10H |
Neoprene |
Phosphorus Bronze Steel Wire |
| H717 |
Vapor |
7/8" |
|
12H |
Neoprene |
Phosphorus Bronze Steel Wire |
| H718 |
Vapor |
1" |
|
12H |
Neoprene |
Phosphorus Bronze Steel Wire |
| H727 |
Vapor |
1-1/4" |
|
20H |
Neoprene |
Phosphorus Bronze Steel Wire |
This non-porous vapor hose is oil and heat resistant. The coil wire reinforcement allows for tight radius bends without restricting flow. This is the preferred hose for making the connection from the converter fuel outlet to the carburetor fuel inlet.
| Part Number |
Type |
I.D |
O.D |
Clamp Size |
45° Female Flare hose end |
Material |
Reinforcement |
Working Pressure |
| H723 |
Water |
1/4" |
|
U5 |
4797-4B |
Rubber |
Single braid nylon |
300 P.S.I. |
| H745 |
Water |
5/16"" |
|
U5 |
N/A |
Rubber |
Single braid nylon |
200 P.S.I. |
| H704 |
Water |
3/8" |
|
6H |
4739-6B |
Rubber |
Single braid nylon |
200 P.S.I. |
| H714 |
Water |
1/2" |
|
8H |
4797-8B |
Rubber |
Single braid nylon |
200 P.S.I. |
| H706 |
Water |
5/8" |
|
10H |
N/A |
Rubber |
Single braid nylon |
200 P.S.I. |
| H707 |
Water |
3/4" |
|
12H |
N/A |
Rubber |
Single braid nylon |
200 P.S.I. |
This oil and grease resistant hose is for all coolant connections. It is also suitable for use in making the vapor connection from the converter fuel outlet to the carburetor fuel inlet, when the application does not require tight radius bends. Water hose is used for making PCV connections as well.
